8.5M L3CMOS USB3.0 Stereo Biological C-mount Microscope Camera
$485.30
Manufacturer: Nanjing Amada Instruments Co,, Ltd
Product Code: L3CMOS08500KPA
- Description
- Size Guide
- SPECIFICATION
- Vendor Info
- More Products
Description
8.5M L3CMOS USB3.0 Stereo Biological C-mount Microscope Camera
Description for 8.5M L3CMOS USB3.0 Stereo Biological C-mount Microscope Camera
L3CMOS is Luxurious USB3.0 CMOS camera with frame buffers and it adopts ultra-high performance CMOS sensor as the image-picking device, and USB3.0 is used as the data transfer interface.
L3CMOS comes with advanced video & image processing application ToupView; Providing Windows/Linux/ OSX multiple platforms SDK; Native C/C++, C#/VB.NET, DirectShow, Twain Control API;
The L3CMOS can be widely used in bright field light environment and microscope image capture and analysis.
The basic characteristic of L3COMS cameras are as follows:
- C-Mount camera has 25.4 mm or 1 inch diameter with 32 threads per inch;
- Scientific research grade camera with Aptina CMOS sensor;
- With hardware resolution among 1.2M to 14M;
- On-board memory for perfect synchronization,higher frame rate and stable performance;
- High performance cooling structure, ensures low image noise;
- 0 5 Gbps interface ensuring high frame rate;
- Ultra-FineTM color engine with perfect color reproduction capability;
- With advanced video & image processing application ToupView;
- Providing Windows/Linux/Mac OS multiple platforms SDK;
- Native C/C++, C#/VB.NET, DirectShow, Twain Control API;
| Order Code | Sensor & Size(mm) | Pixel
(μm) |
G Responsivity
Dynamic range SNRmax |
FPS/Resolution | Binning | Exposure |
| L3CMOS08500KPA LP108500A |
8.5M/Special(C) 1/2.4“(5.56×4.26 |
1.67×1.67 | 0.31v/lux-sec
65.2dB 34dB |
8.3@3328×2548 26.2@1664×1272 |
1×1 2×24×4 |
0.1ms~2000ms |
C: Color; M: Monochrome;
| Other Specification for L3CMOS Camera | |
| Spectral Range | 380-650nm (with IR-cut Filter) |
| White Balance | ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor |
| Color Technique | Ultra-FineTM Color Engine/NA for Monochromatic Sensor |
| Capture/Control SDK | Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc) |
| Recording System | Still Picture and Movie |
| Cooling System* | Natural with High Performance Cooling Structure |
| Operating Environment | |
| Operating Temperature(in Centidegree) | -10~ 50 |
| Storage Temperature(in Centidegree) | -20~ 60 |
| Operating Humidity | 30~80%RH |
| Storage Humidity | 10~60%RH |
| Power Supply | DC 5V over PC USB Port |
| Software Environment | |
| Operating System | Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit)
OSx(Mac OS X) Linux |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher |
| Memory:2GB or More | |
| USB Port:USB3.0 High-speed Port | |
| Display:17” or Larger | |
| CD-ROM | |
| Order Code | Sensor & Size(mm) | Pixel
(μm) |
G Responsivity
Dynamic range SNRmax |
FPS/Resolution | Binning | Exposure |
| L3CMOS08500KPA LP108500A |
8.5M/Special(C) 1/2.4“(5.56×4.26 |
1.67×1.67 | 0.31v/lux-sec
65.2dB 34dB |
8.3@3328×2548 26.2@1664×1272 |
1×1 2×24×4 |
0.1ms~2000ms |
C: Color; M: Monochrome;
| Other Specification for L3CMOS Camera | |
| Spectral Range | 380-650nm (with IR-cut Filter) |
| White Balance | ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor |
| Color Technique | Ultra-FineTM Color Engine/NA for Monochromatic Sensor |
| Capture/Control SDK | Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc) |
| Recording System | Still Picture and Movie |
| Cooling System* | Natural with High Performance Cooling Structure |
| Operating Environment | |
| Operating Temperature(in Centidegree) | -10~ 50 |
| Storage Temperature(in Centidegree) | -20~ 60 |
| Operating Humidity | 30~80%RH |
| Storage Humidity | 10~60%RH |
| Power Supply | DC 5V over PC USB Port |
| Software Environment | |
| Operating System | Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit)
OSx(Mac OS X) Linux |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher |
| Memory:2GB or More | |
| USB Port:USB3.0 High-speed Port | |
| Display:17” or Larger | |
| CD-ROM | |
