Name: Barnstead Pacific TII Water Purification System
Availability: InStock

Barnstead Pacific TII Water Purification System

Barnstead Pacific TII Water Purification System

Price range: $6,851.40 through $10,103.40

Barnstead Pacific TII Water Purification System

Manufacturer: Thermofisher Scientific

VIDEO

SKU: N/A

Product code	50131982 50132123 50132124 50132125 50132131 50132132
Flow Rate	20 L/hr. at 10°C 7 L/hr. at 10°C 12 L/hr. at 10°C
Description	Pacific TII 20 (UV) Pacific TII 7 Pacific TII 12 Pacific TII 20 Pacific TII 7 (UV) Pacific TII 12 (UV)
Permeate performance	20 L/hr. at 10°C 7 L/hr. at 10°C 12 L/hr. at 10°C Clear

Add to wishlist

Description

Barnstead Pacific TII Water Purification System

Convert tap water into Type 2, high purity water with the automatic and cost-efficient Thermo Scientific™ Barnstead Pacific TII Water Purification System. This system supports daily requirements from 20 to 200 liters. It removes approximately 98% of inorganic ions and 99% of all dissolved organic substances, as well as microorganisms and particles, with its high performance, reverse osmosis membrane.

Multiple Options for Type 2 water:

Five system options with permeate flows of 3, 7, 12, 20 or 40L/hr
Future system upgrades accommodate greater capacities to meet growing water demands
Space-saving design permits benchtop installation or wall mounting with integrated mounting bracket

Operational Reliability:

Microprocessor controlled for automatic operation with continuous monitoring of all critical parameters
Automatic return to “operating” mode ensures recirculation during standstill periods
UV lamp prevents biological contamination (UV models only)

Easy-to-Operate:

Resistivity/conductivity clearly displayed on large, back-lit control panel that tilts for optimum viewing
Status of current operating mode clearly indicating Production, Stand-by and Cleaning modes
Reservoir fill-level shown as %
System parameters are code-protected to prevent accidental changes to set points

GLP-Compliant Documentation:

Optional printer connects to RS-232 port for data recording and traceability
Cell constant of 0.01cm^-1 ensures precise conductivity measurements
Temperature compensation for the conductivity measurement has an accuracy of ±0.1°C (in conformity with USP 645)

Optional Hand Dispenser:

Gain increased flexibility by adding a hand dispenser with 3-meter cord which connects to tank; use only with a tank equipped with a pressure pump (06.5032, 06.5062, 06.5082). Ships with a 0.2 micron final filter (Part #50138221)

Additional information

Weight	N/A
Product code	50131982, 50132123, 50132124, 50132125, 50132131, 50132132
Flow Rate	20 L/hr. at 10°C, 7 L/hr. at 10°C, 12 L/hr. at 10°C
Description	Pacific TII 20 (UV), Pacific TII 7, Pacific TII 12, Pacific TII 20, Pacific TII 7 (UV), Pacific TII 12 (UV)
Permeate performance	20 L/hr. at 10°C, 7 L/hr. at 10°C, 12 L/hr. at 10°C

Frequency	50/60 Hz
Feedwater Connector	3/4 in. NPT
Product Water Type	Type 2
TOC Monitor with UV Intensity Monitoring	No
Type	Water Purification System
Resistivity	10 to 1 Mohm.cm at 25°C
Conductivity	0.1 to 1.0μS/cm
Daily Output	20 to 200 L
Feedwater Source	Tap
Total Organic Carbon	<30 ppb
Bacterial Content	99%
Particles >0.2µM/mL	<1 μM/mL
Feed Water Monitoring	No
Feedwater Pressure	1 to 6 bar
Height (Metric)	613 mm
Width (Metric)	372 mm
Net Weight (Metric)	25 kg
Operating Pressure	2 to 6 bar
Voltage	90/240 V
Temperature Range (Metric)	2°C to 35°C
Bacterial retention	99%
Depth (Metric)	330 mm
Electrical Requirements	90/240 V 50/60 Hz
Unit Size	Each
