Polarimeter tube 200mm, stainless steel, for ADP450
$736.91
Polarimeter tube 200mm, stainless steel, for ADP450
MANUFACTURER: SI ANALYTICS
- Description
- Size Guide
- DATASHEET
- SPECIFICATIONS
- Vendor Info
- More Products
Description
Polarimeter tube 200mm, stainless steel, for ADP450
Bellingham + Stanley polarimeter tubes 200mm are manufactured to high quality standards conforming to ICUMSA recommendations and are compatible with most makes of polarimeter. Tube ends are precision ground with windows made from specially selected low strain glass in order to achieve highest accuracy optical rotation measurement.
These special XPC tubes are specifically designed for use with our ADP450 digital polarimeter incorporating XPC Technology. XPC technology provides rapid Peltier temperature control of the sample without the need for a cumbersome and costly water bath. Being manufactured of stainless steel, the temperature response of the whole system is far superior than that when using a glass tube – XPC Technology.
Specifications of Polarimeter tube 200mm, stainless steel, for ADP450
| General Specifications | |
| Code | 35-91 |
| Tube Material | Stainless steel |
| End Cap Material | Stainless steel |
| Inlet/Outlet | Two, straight |
| Length | 200mm |
| Collar Size | 30mm (ICUMSA Standard) |
| Internal Diameter | 8mm |
| Volume | 13 ml |
| Window Material | Glass |
| Transmission | 400-1500 nm |
| Seal (tube/end cap) | Screw thread |
| Spare Parts | |
| Window (Cover Glass) | 37-540 |
| Washers | 37-541 |
