Truflo Flange Gaskets – Lotorq LT Series

Manufacturer: ICON PROCESS  CONTROLS

Features

  • Bolt Torque Reduced by Up to 75%
  • Double Raised O-Ring Design
  • Raised Tab – No Pinched Fingers
  • Perfect for Plastic Piping Systems
  • Excellent Chemical Resistance
SKU: N/A
Clear
Add to wishlist

Description

Truflo Flange Gaskets – Lotorq LT ½”-12″

Lotorq LT SERIES

Full Faced ANSI Flange Gaskets

Excellent for Non Metallic Piping Systems
Reduce Flange Breakage

EPDM PTFE   {LoTorq “Sealing made Simple”}

SERIES : LT
SIZES : EPDM ½” – 12″
PTFE | EPDM ½” – 12
CLASS : ANSI 150 Full Faced
TEMP RANGE : EPDM : (-40° to 90°C) (-40° to 194°F)
PTFE : (-40° to 121°C) (-40° to 250°F)

Full Face Flange Gaskets
> Bolt Torque Reduced by Up to 90%
> Double Raised O-Ring Design
> Raised Tab – No Pinched Fingers
> Perfect for Plastic Piping Systems
> Excellent Chemical Resistance



EPDM | Teflon Flange Gaskets are recommended for all types of Non- Metal Plastic flanges to Prevent Initial Breakage due to Bolt Over-Tightening. The unique Double Convex Raised O-Ring Design provides Excellent Sealing with 75% Less Bolt torque required for flat face gaskets. The PTFE gaskets have PTFE Teflon® sheet material bonded directly to EPDM.

Flange gaskets - lotorq lt series

Features:

  • Bolt Torque Reduced by Up to 75%
  • Double Raised O-Ring Design
  • Raised Tab – No Pinched Fingers
  • Perfect for Plastic Piping Systems
  • Excellent Chemical Resistance

More Features:

  • Industry’s Only Full Port Double O-Ring Design for
  • ½ – 12″ Piping Systems
  • Reduces Pressure Drop
  • Location Tab-Eliminates pinched fingers
  • Low Flange Bolt Torques Required for Positive Seal – Due to the Molded Raised Face – Patented double convex
    Ring Design
  • Ideal for Thermoplastic Piping Systems, also Metal or Plastic Lined Metal Pipe Systems for up to 250 psi
  • Excellent Chemical Resistance – PTFE-bonded gaskets
    are Suitable for Extremely Aggressive Chemical Services.
  • Longer Gasket Life – Because Lower Flange Pressures are Required for Sealing. PTFE is Energized by EPDM Backing.
  • Low Torque – Raised O-Ring Design
  • Designed to Provide Positive Seal
  • No Over-Tightening Required
  • Reusable



Flange gaskets - lotorq lt seriesFlange gaskets - lotorq lt series

Additional information

Size

½", ¾", 1", 1½", 2", 3", 4", 6", 8", 10", 12"
Material

EPDM, PTFE

lotorq-lt-series-datasheet



SIZE EPDM PTFE
Part Number Part Number
½” LTE0005 LTPT0005
¾” LTE0075 LTPT0075
1″ LTE0100 LTPT0100
1½” LTE0150 LTPT0150
2″ LTE0200 LTPT0200
3″ LTE0300 LTPT0300
4″ LTE0400 LTPT0400
6″ LTE0600 LTPT0600
8″ LTE0800 LTPT0800
10″ LTE1000 LTPT1000
12″ LTE1200 LTPT1200
