• Objective 45°c:0° color measurement –  to measure color as you see it
• 20° and 60° gloss measurement to clearly differentiate medium to high gloss samples
• Quantification of fluorescence to predict long term color stability
• Special Jetness mode guarantees repeatable and reliable measurement results even for the deepest black
• Compact and lightweight design with sample opening “top and front” to best suit different sample sizes
• Large color touch display with icon-based menu for ease-of-use
• Live preview of the measurement spot to avoid false readings
• Smart high tech LEDs with peak performance for digital standards
• Exchange of digital standards between Benchtop and portable instrument to guarantee seamless global
  color management over the complete supply chain – without any extra profiling
• Professional data analysis with smart-chart

Technical Properties

• • Measuring Capability

    Color, Gloss, Fluorescence, Jetness

Color Measurement

• • Color Geometry

    45°c:0°

  • Sample Port

    32 mm, 12 mm, 04 mm

  • Measuring Area

    22 mm, 08 mm, 04 mm

  • Spectral Range Colorimetric

    400 – 700 nm, 10 nm resolution

  • Spectral Range Fluorescence

    300 – 760 nm, 10 nm resolution

  • Measurement Range

    0 – 170% remission

  • Repeatability Color

    0.01 ΔE94 (10 readings on white)

  • Reproducibility Color

    0.1 ΔE94 (average of 12 BCRA II tiles)

  • Color Systems

    CIELab/Ch, Lab (h), XYZ, Yxy

  • Color Indices

    YIE313, YID1925, WIE313, CIE, Berger, Color Strength, Opacity, Metamerism, Grayscale

  • Illuminants

    A, C, D50, D55, D65, D75, F2, F6, F7, F8, F10, F11, UL30

  • Observer

    2°, 10°

General

• Memory

  4,000 standards and 10,000 samples

• Interface

  USB-cable, LAN

• Display

  5″ Capacitive Color Touchscreen

• Languages

  Chinese English French German Italian Japanese Russian Spanish

• Power supply

  12 V DC; max. 3 A

• Weight

  7 kg

• Weight

  15.5 lb

• Operating temperature

  10 – 40 °C

• Storing temperature

  0 – 60 °C

• Operating temperature

  50 – 104 °F

• Storing temperature

  32 – 140 °F

• Relative humidity

  Up to 85% at 35 °C (95 °F), non-condensing

• Dimensions: L x W x H

  39 x 26 x 19 cm

• Dimensions: L x W x H

  15.35 x 10.2 x 7.5 in

• Gloss Measurement

  	20°	60°
  Measurement Range Gloss	0 – 100 GU	0 – 100 GU
  Aperture Size	9 x 10 mm	9 x 16 mm
  Repeatability	0 – 100 GU: ± 0.2 GU	0 – 20 GU: ± 0.1 GU 20 – 100 GU: ± 0.2 GU
  Reproducibility	0 – 100 GU: ± 1.0 GU	0 – 20 GU: ± 0.5 GU 20 – 100 GU: ± 1.0 GU
