CCTV Tester T Series DT-T60 (HD+IPC+Analog)
$364.60
CCTV Tester T Series DT-T60 (HD+IPC+Analog)
Series:T-Series
Manufacturer: Guangzhou Dongtai electronics CO., LTD
Product code: AMI-805-2
- Description
- Size Guide
Description
Description
CCTV TESTER T SERIES DT-T60 (HD+IPC+ANALOG)
DT-T60 support Analog SD,HD IPC,Basic on ONVIF highly compatible,Ergonomic design,Operate with single hand,Real time operation prompt
General Description
- Support Analog SD, HD IPC
- Step by step IPC test, quickly locate failure
- ONVIF highly compatible
- Ergonomic design, operate with single hand.
- Real time operation prompt
- 12V/1A power output
- Dual 100M network port，capable of detecting packet lost, monitoring network flow.
- 4.0 inch all viewing angle display，800X480 resolution, 16.7M color
- Swing keyboard input, QWERTY.
- Changeable Li-polymer battery, battery working time 10 hours
- With rubber protection layer
- Dual LED torch
- Software upgrade online
Features
- Support Both Onvif HD IP Camera and Digital Analog Camera System testing;
- Compatible with Axis, Samsung, Sony, Bosch, Panasonic, Vivotek, Dahua and Hikvision’s IP Camera.
Specifications
|
model |
DT-T60 |
|
interface |
|
|
Network interface |
Dual 10/100M RJ45，support switch mode |
|
Function interface |
Dual BNC connector（Video input/output），RS485comm，audio input，USB, reset button |
|
IPC test |
|
|
protocol |
ONVIF 2.4.1, RTSP, RTP |
|
Ethernet test |
10/100MLink test；link speed test；Ethernet loop detect；Ethernet flow monitor；Link quality indicator； |
|
IP Setting |
Manual IP/ DHCP client/ DHCP Server/Multiple DHCP detect/auto DHCP status switching |
|
IPC Test |
Discover, inter-subnet discover,camera list, camera snapshot for fast camera indication, real time video, camera network setting, PTZ test, audio test, full screen display of video, digital zoom of video( 8step), save snapshot, record video(original stream), UDP/TCP switching, packet lost indicator, camera profile setting. |
|
Hikvision camera activate |
Automatic detect. |
|
Analog SD test |
|
|
SD standard |
NTSC, PAL |
|
Video resolution |
D1 |
|
Signal level |
1Vpp |
|
Camera test |
Real time video, PTZ control, audio test, full screen preview, digital zoom of video(8 step), save snapshot, record video(h.264), video resolution and frame rate indicator. |
|
PTZ controller |
|
|
Communication protocol |
Hikvision、Pelco-D/P、Samsung、Panasonic、Lilin、Yaan…more than 30 protocols |
|
Baud rate |
150, 300, 600, 1200, 2400, 4800, 9600, 19200bps |
|
Other test |
|
|
Network analysis |
Sniff, list sub-net,ping |
|
Video generator |
Send PAL/NTSC of various test pattern to output |
|
Record playback |
Local playback, snapshot and video digital zoom, video frame by frame play support |
|
device |
|
|
Display |
4.0inch TFT 800*RGB*480(WVGA) resolution，16.7M color，back light level adjustable |
|
Internal storage |
8GB flash |
|
LED torch |
Two 35lm LED, can turn on individually when device is off. |
|
Operation |
Power button, main control keypad of 12 keys, swing QWERTY keyboard of 45 keys. |
|
Language |
Chinese,English,French,Spanish,Germany,Turkish,Russian |
|
Keypad tone |
On/Off |
|
Software upgrade |
Online upgrade |
|
power |
|
|
battery |
Dedicate li-polymer battery, user replaceable, capacity 11Wh |
|
Power output |
12V/1Aoutput |
|
Battery work time |
Charge 3~4 hours，working time 5 hours |
|
other |
|
|
Working temperature |
-10℃~+55℃ |
|
Working humidity |
30%~90% |
|
Device Dimension |
190x113x37mm |
|
Weight |
0.5kg(device with battery) / 1.6kg(gross) |
